牌號 |
型號 |
AWS |
熔敷金屬化學成分(wt.%) |
熔敷金屬機械性能 |
|||||||||||||
|
C |
Mn |
Si |
S |
P |
Cr |
Ni |
Mo |
V |
其他 |
R m (MPa) |
ReL (MPa) |
A (%) |
KV2(J) |
PWHT |
|||
|
J607RH |
E6215- N2M1 |
E9015-G |
≤0.12 |
0.70-1.50 |
≤0.80 |
≤0.015 |
≤0.020 |
— |
0.80-1.50 |
0.10-0.40 |
— |
— |
≥620 |
≥530 |
≥17 |
-40℃ ≥54 |
620℃×1h |
|
J607QR |
E6215- N5M1 |
E9015-G |
≤0.12 |
0.60-1.20 |
≤0.80 |
≤0.015 |
≤0.020 |
— |
2.0-2.75 |
≤0.30 |
— |
— |
≥620 |
≥530 |
≥17 |
-60℃ ≥54 |
580℃×6h |
|
E7615-G |
E11015-G |
≤0.10 |
≥1.00 |
≤0.60 |
≤0.020 |
≤0.020 |
≤0.20 |
2.00-2.60 |
0.40-0.70 |
— |
— |
≥760 |
≥670 |
≥15 |
-50℃ ≥54 |
620℃×1h |
|
|
J857CrNi |
E8315-G |
E12015-G |
≤0.10 |
1.30-2.25 |
≤0.60 |
≤0.020 |
≤0.020 |
0.30-1.50 |
1.75-2.50 |
0.30-0.55 |
≤0.05 |
— |
≥830 |
≥740 |
≥12 |
-50℃ ≥54 |
620℃×1h |
|
牌號 |
型號 |
AWS |
熔敷金屬化學成分(wt.%) |
熔敷金屬機械性能 |
|||||||||||||
|
C |
Mn |
Si |
S |
P |
Cr |
Ni |
Mo |
V |
其它 |
R m (MPa) |
ReL (MPa) |
A (%) |
KV2 (J) |
PWHT |
|||
|
J427HIC |
E4315 |
— |
≤0.20 |
≤1.20 |
≤1.00 |
≤0.010 |
≤0.010 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥430 |
≥330 |
≥20 |
-30℃ ≥54 |
620℃×4h |
|
J507 |
E5015 |
E7015 |
≤0.15 |
≤1.25 |
≤0.75 |
≤0.015 |
≤0.025 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥490 |
≥400 |
≥22 |
-30℃ ≥54 |
— |
|
J507HIC |
E5015 |
E7015 |
≤0.15 |
≤1.60 |
≤0.90 |
≤0.010 |
≤0.010 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥490 |
≥400 |
≥20 |
-30℃ ≥54 |
620℃×1h |
|
J506 |
E5016 |
E7016 |
≤0.15 |
≤1.60 |
≤0.75 |
≤0.015 |
≤0.025 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥490 |
≥400 |
≥22 |
-30℃ ≥54 |
— |
|
J506Fe |
E5018 |
E7018 |
≤0.15 |
≤1.60 |
≤0.75 |
≤0.015 |
≤0.025 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥490 |
≥400 |
≥22 |
-30℃ ≥54 |
— |
|
J506Fe-1 |
E5018-1 |
E7018-1 |
≤0.15 |
≤1.60 |
≤0.75 |
≤0.015 |
≤0.025 |
≤0.20 |
≤0.30 |
≤0.30 |
≤0.08 |
— |
≥490 |
≥400 |
≥22 |
-45℃ ≥54 |
— |
|
W707Ni |
E5015-G |
E7015-G |
≤0.12 |
≤1.25 |
≤0.50 |
≤0.015 |
≤0.020 |
— |
2.0-2.75 |
— |
— |
— |
≥490 |
≥400 |
≥22 |
-70℃ ≥54 |
620℃×1h |
|
W707DQ |
E5015-G |
E7015-G |
≤0.12 |
≤1.25 |
≤0.50 |
≤0.015 |
≤0.020 |
— |
2.0-2.75 |
— |
— |
— |
≥490 |
≥400 |
≥22 |
-70℃ ≥54 |
620℃×1h |
|
J507RH |
E5015-N1 |
E7015-G |
≤0.12 |
0.60-1.60 |
≤0.90 |
≤0.015 |
≤0.025 |
— |
0.30-1.00 |
≤0.35 |
≤0.05 |
— |
≥490 |
≥410 |
≥25 |
-40℃ ≥54 |
620℃×1h |
|
J557RH |
E5515-N1 |
E8015-G |
≤0.12 |
0.60-1.60 |
≤0.90 |
≤0.015 |
≤0.025 |
— |
0.30-1.00 |
≤0.35 |
≤0.05 |
— |
≥550 |
≥460 |
≥20 |
-40℃ ≥54 |
620℃×1h |
|
J558Ni |
E5518-N2 |
E8018-C3 |
≤0.12 |
0.40-1.25 |
≤0.80 |
≤0.015 |
≤0.020 |
≤0.15 |
0.80-1.10 |
≤0.35 |
≤0.05 |
— |
≥550 |
≥470 |
≥20 |
-40℃ ≥54 |
620℃×1h |
|
W107 |
E5015-N7 |
E7015-C2L |
≤0.05 |
≤1.25 |
≤0.50 |
≤0.015 |
≤0.020 |
— |
3.0-3.75 |
— |
— |
— |
≥490 |
≥390 |
≥20 |
-100℃ ≥54 |
605℃×1h |
|
J506NH |
E5016-NCC |
— |
≤0.12 |
0.30-1.40 |
≤0.90 |
≤0.015 |
≤0.025 |
0.45-0.75 |
0.05-0.45 |
— |
— |
Cu:0.30-0.70 |
≥490 |
≥390 |
≥20 |
0℃ ≥54 |
620℃×1h |
|
J556NH |
E5516-G |
— |
≤0.12 |
- |
≤0.60 |
≤0.015 |
≤0.025 |
0.30-0.90 |
0.20-0.60 |
— |
— |
Cu:0.20-0.40 |
≥550 |
≥460 |
≥22 |
-40℃ ≥54 |
620℃×1h |
|
牌號 |
AWS |
GB/T 8110 |
焊絲化學成分(wt.%) |
||||||||||
|
C |
Mn |
Si |
P |
S |
Cr |
Ni |
Mo |
Cu |
V |
其它 |
|||
|
ER55-B2 |
ER80S-B2 |
ER55-B2 |
0.07-0.12 |
0.40-0.70 |
0.40-0.70 |
≤0.025 |
≤0.025 |
1.20-1.50 |
≤0.20 |
0.40-0.65 |
≤0.35 |
— |
≤0.50 |
|
ER55-B2(H) |
ER80S-B2 |
ER55-B2 |
0.07-0.12 |
0.40-0.70 |
0.40-0.70 |
≤0.020 |
≤0.010 |
1.20-1.50 |
≤0.20 |
0.40-0.65 |
≤0.35 |
— |
≤0.50 |
|
ER55-B2MnV |
— |
ER55-B2MnV |
0.06-0.10 |
1.20-1.60 |
0.60-0.90 |
≤0.030 |
≤0.025 |
1.00-1.30 |
≤0.25 |
0.50-0.70 |
≤0.35 |
0.20-0.40 |
≤0.50 |
|
ER62-B3 |
ER90S-B3 |
ER62-B3 |
0.07-0.12 |
0.40-0.70 |
0.40-0.70 |
≤0.025 |
≤0.025 |
2.30-2.70 |
≤0.20 |
0.90-1.20 |
≤0.35 |
— |
≤0.50 |
|
ER80S-B6 |
ER80S-B6 |
— |
≤0.10 |
0.40-0.70 |
≤0.50 |
≤0.025 |
≤0.025 |
4.50-6.00 |
≤0.30 |
0.45-0.65 |
≤0.35 |
— |
≤0.50 |
|
ER55-Ni1 |
ER80S-Ni1 |
ER55-Ni1 |
≤0.12 |
≤1.25 |
0.40-0.80 |
≤0.025 |
≤0.025 |
≤0.15 |
0.80-1.10 |
≤0.35 |
≤0.35 |
≤0.05 |
≤0.50 |
|
ER55-Ni2 |
ER80S-Ni2 |
ER55-Ni2 |
≤0.12 |
≤1.25 |
0.40-0.80 |
≤0.025 |
≤0.025 |
— |
2.00-2.75 |
— |
≤0.35 |
— |
≤0.50 |
|
H09MnNiDR |
ER80S-Ni3 |
ER55-Ni3 |
≤0.12 |
≤1.25 |
0.40-0.80 |
≤0.025 |
≤0.025 |
— |
3.00-3.75 |
— |
≤0.35 |
— |
≤0.50 |
|
ER55-Ni3 |
ER80S-Ni3 |
ER55-Ni3 |
≤0.12 |
≤1.25 |
0.40-0.80 |
≤0.025 |
≤0.025 |
— |
3.00-3.75 |
— |
≤0.35 |
— |
≤0.50 |
|
ER50-3HIC |
ER70S-3 |
ER50-3 |
0.06-0.15 |
0.90-1.40 |
0.45-0.75 |
≤0.015 |
≤0.025 |
≤0.15 |
≤0.15 |
≤0.15 |
≤0.50 |
— |
≤0.50 |
|
ER50-6HIC |
ER70S-6 |
ER50-6 |
0.06-0.15 |
1.40-1.85 |
0.80-1.15 |
≤0.015 |
≤0.025 |
≤0.15 |
≤0.15 |
≤0.15 |
≤0.50 |
≤0.03 |
≤0.50 |
|
ER55-D2 |
ER80S-D2 |
ER55-D2 |
0.07-0.12 |
1.60-2.10 |
0.50-0.80 |
≤0.025 |
≤0.025 |
— |
≤0.15 |
0.40-0.60 |
≤0.50 |
— |
≤0.50 |
|
類別 |
牌號 |
AWS A5.29 GB/T 17493 |
熔敷金屬化學成分(wt.%) |
熔敷金屬力學性能 |
PWHT |
|||||||||||
|
C |
Mn |
Si |
P |
S |
Cr |
Ni |
Mo |
V |
R m (MPa) |
ReL (MPa) |
A (%) |
KV2 (J) |
||||
|
耐熱鋼CO2氣體保護 |
STL-81B2/M STLR307 |
E81T1-B2C T55T1-1C1-1CM |
0.05-0.12 |
≤1.25 |
≤0.80 |
≤0.030 |
≤0.030 |
1.00-1.50 |
— |
0.40-0.65 |
— |
550-690 |
≥470 |
≥19 |
— |
690*1h |
|
STL-81B2V/M STLR317 |
E81T1-B2C T55T1-1C1-G1CMV |
≤0.12 |
≤1.50 |
≤0.90 |
≤0.030 |
≤0.030 |
1.00-1.50 |
— |
0.40-0.65 |
0.10-0.35 |
≥550 |
≥470 |
≥19 |
— |
730*2h |
|
|
類別 |
牌號 |
AWS A5.29 GB/T 10045 |
熔敷金屬化學成分(wt.%) |
熔敷金屬力學性能 |
PWHT |
|||||||||||
|
C |
Mn |
Si |
P |
S |
Cr |
Ni |
Mo |
V |
R m (MPa) |
ReL (MPa) |
A (%) |
KV2 (J) |
— |
|||
|
低溫鋼CO2氣體保護 |
STL-81K2/M |
E81T1-K2C E556T1-1C1A-N3 |
≤0.15 |
0.50-1.75 |
≤0.80 |
≤0.030 |
≤0.030 |
≤0.15 |
1.00-2.00 |
≤0.35 |
≤0.05 |
550-690 |
≥470 |
≥19 |
-60℃ ≥27 |
— |
|
STL-81Ni1/M |
E81T1-Ni1C E554T1-1C1A-N2 |
≤0.12 |
≤1.5 |
≤0.80 |
≤0.030 |
≤0.030 |
≤0.15 |
0.80-1.10 |
≤0.35 |
≤0.05 |
550-690 |
≥470 |
≥19 |
-40℃ ≥27 |
— |
|
|
STL-81Ni2/M |
E81T1-Ni2C E554T1-1C1A-N5 |
≤0.12 |
≤1.5 |
≤0.80 |
≤0.030 |
≤0.030 |
— |
1.75-2.75 |
— |
— |
550-690 |
≥470 |
≥19 |
-40℃ ≥27 |
— |
|
